perkins 2000kva diesel generator set data

ENGINE DATA
Manufacturer / Model: Perkins 4016TAG2A，4-cycle
Air Intake System: Turbo, Air/Air cooling
Fuel Injection System: Direct Injection
Cylinder Arrangement: 16 in “V”
Displacement: 61.123 L
Bore and Stroke: 160×190（mm）
Compression Ratio: 13.6
Rated RPM: 1500rpm
Max. Standby Power at Rated RPM: 1937KW/2635HP
Governor Type: Electronic

Alternator Data
Number of Phase: 3
Connecting Type: 3 Phase and 4 Wires, “Y” type connecting
Number of Bearing: 1
Power Factor: 0.8
Protection Grade: IP23
Altitude: ≤1000m
Exciter Type: Brushless, self-exciting
Insulation Class, Temperature Rise: H/H
Telephone Influence Factor (TIF): ＜50
THF: ＜2%
Voltage Regulation, Steady State: ≤±1%
Alternator Capacity: 2080KVA
Alternator Efficiencies: 96.4%
Air Cooling Flow: 2.69m3/s

Standard Configuration (Open Type)
Overall Size: 5710（mm）×2775（mm）×3350（mm）
Weight: 13500kg

Yangzhou YangKe Machinery Electrical Co.,LTD., Wasfounded in 2004,it is one of generators manufacturers in China.

At YangKe, you can choose generators and emergency gensets in sizes from 3 to 2500KW. We only offer products using major engine brands such as Cummins, Perkins, Doosan, MTU Diesel/Mitsubishi etc.

At YANGKE, we also customize the standard models to meet your unique requirements.

Our Gensets are also top of the line and come with base mounted fuel tanks, battery, battery rack and cables, vibration isolators between engine/diesel genset and base frame, a circuit breaker to protect the generator from overload and a two wire auto start ready controls for automatic transfer switch operation. (Note: Automatic Transfer Switch Required for True Auto Operation)

Our company has been an accredited manufacturer who obtained the authentication of National Inspection and Supervision Center of Gas engine and Generating Sets sice 2000, the quality system certification of ISO9001-2008 Environment and ISO14001 occupation health & safety management.

Our company has advanced detection equipment, modern production technology, professional manufacturing technology and perfect quality management system with a strong R&D and technological strength. We can provide a variety of specifications common automated, automatic cut over, soundproof and mobile and so on high quality, the low energy consumption power set satisfies the customer all electric power set satisfies the customer all electric power demand. We also can satisfy the user different voltage, different frequency request, as well as many units and networking power supply system.

Our products in southeast Asia, central Asia, the Middle East, Africa and South America are used.
